How is the GXP2170 different from the GRP2615?

Both have main + secondary screens. The GRP2615's secondary screen has 40 always-visible multi-color BLF keys (no pagination); the GXP2170's secondary has 6 keys × 8 pages (48 effective, but paginated). The GRP2615 also has built-in Wi-Fi (the GXP2170 needs a USB dongle) and uses the modern GBX20 sidecar. The GRP2615 is the cleaner choice for new deployments.

Does the GXP2170 support a touchscreen?

No. Both displays are non-touch.

Can it use a Wi-Fi dongle?

Yes. Grandstream's USB Wi-Fi dongle plugs into the USB port.

How many BLF keys with full expansion?

208 — 48 native on the side screen plus 160 across four GXP2200EXT sidecars.

Will it auto-provision on voip.army?

Yes. Same XML provisioning flow.

Grandstream · GXP series · legacy flagship

Grandstream GXP217012 lines, secondary BLF screen, top of the GXP line.

A 4.3-inch color TFT, a 2.8-inch secondary color LCD for BLF, twelve SIP accounts, six native programmable keys with multi-page support (48 effective on the side screen), dual gigabit, PoE class 2, built-in Bluetooth, USB, and 4× GXP2200EXT sidecar support. The GXP2170 is the flagship of the legacy GXP catalog.

Display

4.3″ main + 2.8″ BLF screen

SIP accounts

12 lines

Programmable keys

48 effective (6 × 8 pages)

Ethernet

Dual gigabit · PoE class 2

USB + Bluetooth

Built in

Expansion

Up to 4× GXP2200EXT

$229 one-time

or rent for $17.99/mo — month-to-month, return anytime

Ships pre-configured · free next-business-day for orders $200+

Order a GXP2170 Rent for $17.99/mo Datasheet (PDF) ↓

✓ Auto-provisioned out of the box ✓ Warranty replacement included with rental ✓ Free shipping on orders $200+

Grandstream GXP2170 voip desk phone — front view with handset and display — Grandstream GXP2170

Why the GXP2170 is on the catalog.

The GXP2170 is the top of Grandstream's legacy enterprise catalog. Dual displays (4.3-inch main + 2.8-inch BLF secondary), twelve SIP accounts, a programmable-key layout that goes deep enough to be receptionist-capable without a sidecar (48 native keys on the side screen via 6×8 pagination), built-in Bluetooth, USB, support for up to 4 GXP2200EXT sidecars (160 more keys).

It is the GXP-family phone closest in capability to the modern GRP2614 / GRP2615. Twelve lines is plenty for almost any role (and matches the modern 16-line GRP minimum closely enough), the dual-screen layout puts BLF on dedicated real estate instead of competing with caller ID, and the build is the heaviest and most premium-feeling in the GXP line.

Modern equivalent: the GRP2615 is the closest direct replacement — bigger native BLF panel (40 multi-color keys vs the GXP2170's 6-key paginated), built-in Wi-Fi (none on the GXP2170 without a USB dongle), and the modern GBX20 sidecar instead of the older GXP2200EXT. About $40 less than the GXP2170, with more capability. For new deployments, the GRP2615 is the obvious better buy. The GXP2170 is the right pick for extending established GXP2170 fleets or matching existing infrastructure.

Full technical specifications.

Display & user interface
Main display	4.3-inch 480×272 color TFT LCD
Secondary display	2.8-inch 320×240 color LCD with 6 multi-color BLF keys (paginated to 48 effective)
Programmable keys	48 effective (6 keys × 8 on-screen pages)
Soft keys	4 XML soft keys
VoIP & SIP
SIP accounts	12 SIP accounts, 12 lines
Protocols	SIP RFC3261, NAT (STUN), TLS, SRTP, BLF, SCA
Codecs	Opus, G.722, G.711a/u, G.726, G.729A/B, iLBC
Provisioning	TR-069, XML, GDMS
Audio
HD voice	HD handset, HD speaker, HD headset
Headset	RJ9 wired, USB, Bluetooth, EHS via adapter
Connectivity
Ethernet	Dual 10/100/1000 Mbps gigabit
PoE	IEEE 802.3af Class 2
Bluetooth	Built-in Bluetooth 4.0
USB	1× USB 2.0 host port
Wi-Fi	Optional via Grandstream USB Wi-Fi dongle
Expansion
Sidecar	Up to 4× GXP2200EXT
Max effective keys	208 (48 native + 160 via 4× GXP2200EXT)
Physical
Dimensions	245 × 205 × 80 mm
Weight	Approximately 1.15 kg
In the box (from voip.army)
Included	GXP2170 handset, base, curl cord, ethernet cable, stand, provisioning card
Not included	Power adapter (PoE preferred), sidecars if needed

How it works on voip.army.

Plug the GXP2170 into PoE and ethernet. About a minute later it has registered to your extension. Same auto-provisioning flow as every other supported phone — no SIP credentials to type, no firmware to chase.

60s

Time from plug-in to first call

Boot, fetch config from our provisioning server, register, ready. About one minute on a normal connection.

SIP accounts on one phone

12 lines per phone. Each line key has a dual-color LED for status at a glance.

Programmable keys

48 effective (6 × 8 pages) mapped from the voip.army portal — BLF, paging, parking, transfer destinations.

Per-device onboarding fees

Bringing your own? Send the MAC, factory-reset, plug in. No charge to add it to the fleet.

802.3af

PoE class

Standard PoE — any 802.3af-compliant switch from the last 15 years powers the phone without an adapter.

GDMS

Grandstream Device Management

Provisioning template tested against every Grandstream firmware release for GXP2170. We catch regressions before they reach your fleet.

Need GXP2170s for every desk?

Tell us how many you need and what extensions to map. We ship pre-configured next business day; you plug them in and they work.

Get a quote Start a free trial first

✓ Free shipping on orders $200+ ✓ 30-day hardware return ✓ Pre-configured before shipping
